Construction of Kayseri Develi Gümüşören Dam-Kayseri
Client
: 12. Regional Directorate of State Hydraulic Works - Kayseri
Contract Date
: 2011
Final Completion
: 2013
Contract Value
: 49.742.865 TL
The Gümüşören Dam is being built in order to supply energy and irrigation to the region between Kayser-Develi ( as the 2nd phase of the Project)
Technical Characteristics of the Dam;
Dam volume : 2.050.000 m3 (clay core, sand-gravel fill)
RCC Volume : 180.000 m3 rcc (Roller Compacted Concrete)
Height from base : 36.50 m
Height from thalweg : 30.00 m
Crest length : 842,00 m
Crest width : 10.00 m
Storage Volume: 195.000.000 m3
Inner diameter of diversion : 3,50 m
Length of diversion : 47,00 m
HEPP Installed capacity: 5 MW
Annual amount of energy production : 11,90 GWh
